Hello vMix community, I'm happy to announce that We've Open-Sourced Our Entire 4 M/E vMix Production for FIRST Global Slovakia 2025 robotics tournament!What's Inside:
- 📡 Infrastructure topology & venue diagrams
- 📝 Running order & live show script
- 🎛️ vMix 4 M/E presets & input structure
- 🧠 Companion & Winwet button mapping
- 📺 SPX scoreboard overlay (custom template)
- ⏱️ Countdown automation & triggers
- 🎵 Royalty-free music playlist
- 🔀 Hybrid HDMI / NDI / SRT / RTMP workflow
- 🧰 Gear lists, operator notes & more
🔗 Check out the full repository on GitHub: https://github.com/DusanBrejka/first-global-slovakia-2025-productionHappy to answer questions or dive into specifics! It was a fun, complex, and budget-conscious production — perfect for anyone planning esports, robotics, or live sports broadcasts.
|
|
When we create a group of objects (such as a row in a scoreboard), we often use:
- A Mask applied to an image or shape
- A Bounding link where one object follows the position or size of another
- A Storyboard animation triggered by a Data Change
After we finish one row, we usually copy and paste the objects into a new layer to create more rows.
The problem:
When pasting, the linked actions (such as mask, bounding, and storyboard references) still point to the original objects, not the new copies.
So for every duplicated row, we have to manually edit each object to fix its linked references - which becomes extremely repetitive and time-consuming in projects with many rows or layers.
Suggestion:
It would be very helpful if GT Designer could automatically update linked references when pasting objects, so the new elements link to their corresponding copies - instead of the originals.
|
I dont know if suffice or not,because i dont have a sample image to check. Anyway this time i described to AI what to do and it come up with the following. In my example i assume that TitleText1.Text layer is "pair" with Image1.Source and so on until to 10. Code:
Dim a As String
Dim i As Integer
Do While True
For i = 1 To 10
' Διαβάζουμε το αντίστοιχο TitleText{i}.Text
a = Input.Find("[h]scoreboard[/h]").Text("TitleText" & i & ".Text")
' Αν το κείμενο είναι κενό ή μόνο whitespace, κλείνουμε το Image.
If String.IsNullOrWhiteSpace(a) Then
API.Function("SetImageVisibleOFF", Input:="[h]scoreboard[/h]", SelectedName:="Image" & i & ".Source")
Else
API.Function("SetImageVisibleON", Input:="[h]scoreboard[/h]", SelectedName:="Image" & i & ".Source")
End If
Next
Sleep(500)
Loop
i cannot say if it works or not but if yours not work,try it.
|
Hi. This script to my little knowledge it seems to me in-complete. Correct me if i am wrong but i dont see in your code a command like "api function"-->do this when the "if" situation is meet I see in vmix api that exist https://vmixapi.com/?function=SetImageVisibleOn and https://vmixapi.com/?function=SetImageVisibleOff in order to set the image visibility on or off. In your script i dont see something like this,that will tell vmix how to hide/unhide the image when the condition fits Edit. Based in the scripting of dummies thread and https://tvcrew.ch/wiki/d...hp?id=scripting_examples a working script that do what you need will be like this Code:
dim a as string
do while true
a= Input.Find("[h]scoreboard[/h]").Text("Title Text.Text")
if a = "" then
API.Function("SetImageVisibleOFF",Input:="[h]scoreboard[/h]",SelectedName:="Image2.Source")
else
API.Function("SetImageVisibleON",Input:="[h]scoreboard[/h]",SelectedName:="Image2.Source")
end if
sleep(500)
loop
replace with your input title names and try if works
|
Originally Posted by: doggy  Originally Posted by: TL68 Hi!
Building a scoreboard which contains extra graphic elements that I would like to show/hide indipendent of eachother.
Trying to use pages for this but cannot get it to work as needed.
If i assign element 1 to page 1 I need to hide element 2 and 3 on page 1
If i assign element 2 to page 2 I need to hide element 1 and 3 on page 2
If i assign element 3 to page 3 I need to hide element 1 and 2 on page 3
I want to have a shortcut for each individual element that triggers it to show, and so that I can chose any combination to display of the three elements.
Above works if I want to just display each element alone.
But how to solve so that I for example can press shortcut for element 1 (page1) and then element 2 (page2) and both stays displayed at the same time?
If set up as above element 1 will hide when I press element 2 and vice versa.
I hope the question is understandable.
Any solution for this?
each page will show what is defined on it , can not stack pages and look through them just like real world pages Maybe look into hiding/showing each element (use fade for that with very short time) Thanks for responding. Not sure I understand how to use the show/hide method though. Any manual or tutorial around for this?
|
